Siemens S7-1500PLC Process Module

Siemens S7-1500PLC Process Module Counting and Position Detection Module has hardware-level signal processing in the module for fast counting, measuring and position recording of various sensors. Siemens S7-1500PLC module, supports positioning incremental encoders and SSI value encoders. Support centralized and distributed operation. High-speed counting and measuring, fast signal pre-processing, can be operated centrally in S7-1500CPU or in ET200MPI/O.

Siemens S7-1500PLC Process Module Counting and Position Detection Module has hardware-level signal processing functions in the module, which can be used for fast counting, measuring and position recording of various sensors. Supports positioning incremental encoders and SSI value encoders. Supports centralized and distributed operation.

- High-speed counting and measuring, fast signal pre-processing

- Centralized operation in the S7-1500 CPU and distributed operation in the ET 200MP I/O.

The newly released S7-1500 Timestamp module reads the rising and falling edges of discrete input signals and labels them with high-precision timestamp information.

Discrete outputs can also be controlled based on time. In addition, the module supports oversampling, pulse width modulation, counting and other functions. To meet different needs, the module

It helps customers to improve the production efficiency and degree.

- Discrete input signals support time stamp detection, counting, oversampling and other functions.

- The discrete output signal supports time control switching, pulse width modulation, oversampling and other functions.

- It can be applied to electronic cam control, length detection, pulse width modulation, counting and other applications.

SIMATIC S7-1500 Power Supply Module

SIMATIC S7-1500 power supply module is a member of S7-1500 PLC system, which is divided into PS power supply module and PM power supply module.

Based on S7-1500 unified platform design, development and testing as well as the rich experience of Siemens in the field of automation, S7-1500 power supply modules, with their functions and EMC, fully meet the system requirements and are well suited for S7-1500 PLC system.

SIMATIC S7-1500 and ET 200MP TM NPUs

The TM NPU can be installed either on the back of the S7-1500 CPU or on the periphery of the ET 200MP interface module. By installing several modules in succession, the solution can also be expanded according to the number structure and the number of implementable applications.

The S7-1500 TM NPU modules operate using a trained nervous system on an SD card. Users can connect Gigabit Ethernet and USB 3.1-compatible sensors such as cameras and microphones to the module's integrated interface. CPU data transmitted by the backplane bus can also be used as input data. The processing results are then evaluated in the CPU program.

SIWAREX WP521 ST and WP522 ST

These two technology function modules are a beautiful solution for the seamless integration of standard weighing applications, such as bench scales or hopper scales in the SIMATIC S7-1500.

The technology function modules are available in single-channel and dual-channel versions; the SIWAREX WP521 ST is a single-channel version for one scale, while the dual-channel SIWAREX WP522 ST allows the integration of two separate scales into an automation system with the same space requirements.
