Siemens S7-200 Function Modules

The Siemens S7-200 features a consistent modular design. In addition to extension and communication modules, the modular system offers a range of specific extensions for positioning, Siemens 200plc function,Siemens 200plc function module,Siemens 200plc module weighing technology and temperature measurement.The EM 253 is a function module for simple positioning tasks (1 axis). It can be connected to stepper motors and servo motors, and to servo drives via pulse inputs from the Micro Stepper. Siemens 200plc Function,Siemens 200plc Function Module,Siemens 200plc Module EM 253 Positioning Module is mounted in the same way as an extension module and is connected to the S7-200 extension bus via an integrated connection cable.

Description

The SIMATIC S7-200 has a consistent modular design. In addition to the extension and communication modules, the modular system offers a range of specific extensions for positioning, weighing technology and temperature measurement.

Positioning module EM 253

Description: Positioning module EM 253

The EM 253 is a functional module for simple positioning tasks (1 axis). It can be connected to stepper motors and servo motors and to servo drives via frequency pulse inputs from the Micro Stepper.

The EM 253 positioning module is mounted in the same way as an expansion module and is connected to the S7-200 expansion bus via an integrated connection cable.

After connection, the configuration data is read out automatically from the CPU.

The module has the following features:

-For 5-bit inputs from process signals

-24 pulse outputs directly from the drive (forward/backward or speed/direction)

-2 control outputs (DIS; CLR).

-12 status LEDs

weighing module SIWAREX MS

DESCRIPTION: Weighing module SIWAREX MS

The SIWAREX MS is a multipurpose weighing module for various simple weighing and force measurement tasks. The compact module can be easily installed in SIMATIC S7-200 automation systems. The actual weight data can be accessed directly in the SIMATIC CPU without any additional interfaces.

- Measurement of weight or force with 65,000 parts resolution and 0.05% accuracy.

- Easy adjustment of the scale via RS232 interface using the SIWATOOL MS PC program.

- Supports replacement of modules without updating the scale adjustment

- Intrinsic pressure measuring element for use in Ex 2 zones, with power supply for Zone 1 via Ex interface

Thermocouple module EM231 (analog module)

Description: Thermocouple module EM 231 TC

The thermocouple module EM 231 is a temperature sensor with standard thermocouples and precision. Low level analog signals may also be detected in the ±80 mV range. The thermocouple module EM 231 can be used with CPU 222, 224 and 226.

-4 or 8 analog inputs

-Different measuring ranges: thermocouple types J, K, T, E, R, S and N; ±80 mV analog signal acquisition

-Checking of open wiring

-Compensation of cold connection points

- Temperature scale: the measured temperature can be specified as °C or °F.

RTD Module EM231 RTD (Analog Module)

Description: RTD module EM231 RTD

The RTD modules EM231 are precision temperature sensors with a standard resistance temperature detector. They can be used with CPU222, 224 and 226.

The RTD modules should be installed in locations with low temperature fluctuations to ensure accuracy and repeatability.

- Analog input for two or four temperature detectors

- All resistance temperature detectors are of the same type

- Direct mounting on wall or DIN rail
