Our 1769 Compact I/O chassis-based modules can be used as local and distributed I/O for a 1769 CompactLogix L3x, CompactLogix 5370 or Compact GuardLogix 5370 controller. Rack-type features in a rackless design lower costs and reduce replacement parts inventory. A built-in removable terminal block provides connections to I/O sensors and actuators.
Overview
Provides flexibility with DIN Rail or panel mounting options
Includes individual point diagnostic status indicators to ease troubleshooting
Prevents incorrect positioning of module with software keying
Connects as many as three banks of Compact I/O to a controller; requires use of a communication adapter module and power supply
1769 Compact Digital I/O Modules
Offer a variety of AC and DC voltages
Include 8…32 points per module
Include contact output modules
Include high speed input modules
Offer input filtering
Provide optical isolation
1769 Compact Analog I/O Modules
Offer analog, thermocouple, and RTD modules
Provide high accuracy ratings
Include over-range and under-range detection and indication
Include on-board scaling
Offer selectable response to a broken input sensor
Include ability to direct output device operation during an abnormal condition
Provide individually configurable channels
Include autocalibration of inputs
1769-AENTR I/O Modules
Support single network strategy to EtherNet/IP TCP/CIP connection 96
Provide dual Ethernet ports for both DLR and linear topologies
Simplify your system architecture with distributed I/O over EtherNet/IP
Allow control migrations with re-use of existing 1769 I/O
Include I/O packet rate of 10,000 pps
Offer direct connection
1769 Compact Specialty I/O Modules
Address reserve, ASCII, Boolean control, and high-speed counter modules available
Direct 1769 platform connection to drives and other devices through Compact I/O to DPI/SCANport and Compact I/O to DSI/Modbus modules
| Catalog Number | Description |
1768-CNB | ControlNet Bridge Module |
1768-CNBR | ControlNet Redundant Bridge Module |
1768-EWEB | Ethernet/IP Enhanced Web Server Module |
1769-ADN | CompactLogix DeviceNet Adaptor Module |
1769-AENTR | 1769 Network Adaptor,Ethernet,69-I/O,24.0V DC, Dual Port |
1769-AENTRK | 1769 Network Adaptor,Ethernet,69-I/O,24.0V DC, Dual Port, Conformal Coating |
1769-ARM | Address Reserve Module |
1769-ASCII | 2 Channel RS232/RS485/RS422 ASCII Module |
1769-BA | Replacement Battery |
1769-BOOLEAN | 24VDC Input/Output Boolean Control Module |
1769-ECRK | Right End Cap/Terminator - Conformally Coated |
1769-HSC | 2/4 Channel High Speed Counter/Encoder Module |
1769-IA16 | 16 Point 120 VAC Input Module |
| 1769-IA16K | 16 Point 120 VAC Input Module - Conformally Coated |
1769-IA8I | 8 Point 120 VAC Individually Isolated Input Module |
1769-IF16C | 16 Channel Compact High- density Analog Current Input Module |
1769-IF16CK | 16 Channel Compact High- density Analog Current Input Module- Conformally Coated |
1769-IF16V | 16 Channel Compact High- density Analog Voltage Input Module |
1769-IF16VK | 16 Channel Compact High- density Analog Voltage Input Module- Conformally Coated |
1769-IF4 | 4 Channel Analog Current/Voltage Input Module |
1769-IF4K | 4 Channnel Analog Current/Voltage Input Module - Conformally Coated |
1769-IF4FXOF2F | High Resolution, High Speed 4 In/2 Out Analog Combination Module |
1769-IF4I | 4 Channel Analog Current/Voltage Isolated Input Module |
1769-IF4IK | 4 Channel Analog Current/Voltage Isolated Input Module- Conformally Coated |
1769-IF4XOF2 | 8 Bit Resolution, High Speed 4 In/2 Out Anlg. Comb |
1769-IF8 | 8 Channel Analog Current/Voltage Input Module |
1769-IF8K | 8 Channel Analog Current/Voltage Input Module - Conformally Coated |
1769-IG16 | 16 Point 5 VDC TTL Input Module |
1769-IM12 | 12 Point 240 VAC Input Module |
1769-IQ16 | 16 Point 24 VDC Sinking/Sourcing Input Module |
1769-IQ16F | 16 Point High Speed 24VDC Input Module |
1769-IQ16K | 16 Point 24 VDC Sinking/Sourcing Input Module - Conformally Coated |
1769-IQ32 | 32 Point 24VDC Input Module |
1769-IQ32K | 32 Point 24VDC Input Module - Conformally Coated |
1769-IQ32T | 32 Point 24VDC Input Module - Single Wide |
1769-IQ6XOW4 | Combo 6Pt 24 VDC Snk/Src In, 4Pt VAC/VDC Relay Out |
1769-IR6 | 6 Channel RTD/Resistance Input Module |
1769-IR6K | 6 Channel RTD/Resistance Input Module - Conformally Coated |
1769-IT6 | 6 Channel Thermocouple/Mv Input Module |
1769-IT6K | 6 Channel Thermocouple/Mv Input Module - Conformally Coated |
1769-L16ER-BB1B | CompactLogix L16 Controller, 24 VDC Only, Up to 6 Modules Expansion, POINT Bus Backplane, 16 DI (Sink), 16 DO (Source), 2 Ethernet Port (DLR), Up to 4 Ethernet/IP nodes, 384KB User Memory, 1GB SD Card Inbox |
1769-L18ER-BB1B | CompactLogix L18 Controller, 24 VDC Only, Up to 8 Modules Expansion, POINT Bus Backplane, 16 DI (Sink), 16 DO (Source), 2 Ethernet Port (DLR), Up to 8 Ethernet/IP nodes, 512KB User Memory, 1GB SD Card Inbox |
1769-L18ERM-BB1B | CompactLogix L18 Controller, 24 VDC Only, Up to 8 Modules Expansion, POINT Bus Backplane, 16 DI (Sink), 16 DO (Source), 2 Ethernet Port (DLR), Up to 8 Ethernet/IP nodes, 512KB User Memory, 1GB SD Card Inbox. 2 Axes Integrated Motion |
1769-L18ERM-BB1BK | CompactLogix L18 Controller, 24 VDC Only, Up to 8 Modules Expansion, POINT Bus Backplane, 16 DI (Sink), 16 DO (Source), 2 Ethernet Port (DLR), Up to 8 Ethernet/IP nodes, 512KB User Memory 1GB SD Card Inbox. 2 Axes Integrated Motion. Conformal Coated |
1769-L19ER-BB1B | CompactLogix L19 Controller, 24 VDC Only, Up to 8 Modules Expansion, POINT Bus Backplane, 16 DI (Sink), 16 DO (Source), 2 Ethernet Port (DLR), Up to 8 Ethernet/IP nodes, 1MB User Memory, 1GB SD Card Inbox |
1769-L19ER-BB1BK | CompactLogix L19 Controller, 24 VDC Only, Up to 8 Modules Expansion, POINT Bus Backplane, 16 DI (Sink), 16 DO (Source), 2 Ethernet Port (DLR), Up to 8 Ethernet/IP nodes, 1MB User Memory, 1GB SD Card Inbox, Conformal Coated |
1769-L24ER-QB1B | CompactLogix 5370 L2 Controller, 2 EtherNet/IP ports with Device Level Ring Capability, 750KB Memory, 16 DC Inputs, 16 DC Outputs, Up To 4 1769 I/O Expansion Modules, 8 EtherNet/IP and 120 TCP Connections, 24V DC Input Embedded Power Supply,With 1GB SD Card, Can Support Up To 2GB SD Card, 1 USB Port. |
1769-L24ER-QBFC1B | CompactLogix 5370 L2 Controller, 2 EtherNet/IP Ports With Device Level Ring Capability, 750KB Memory, 16 DC Inputs, 16 DC Outputs, 4 Universal Analog Inputs, 2 Analog Outputs, 4 High Speed Counters, Up To 4 1769 I/O Expansion Modules, 8 EtherNet/IP And 120 TCP Connections, 24V DC Input Embedded Power Supply, With 1GB SD card, Can Support Up To 2GB SD Card, 1 USB Port. |
1769-L24ER-QBFC1BK | CompactLogix 5370 L2 Controller, Dual Ethernet w/DLR capability, 750KB Memory, 4 I/O Expansion, 8 Ethernet IP Nodes, 24VDC. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. - Conformally Coated |
1769-L27ERM-QBFC1B | CompactLogix 5370 L2 Controller, 2 EtherNet/IP Ports with Device Level Ring Capability, 1MB Memory, 16 DC Inputs, 16 DC Outputs, 4 Universal Analog Inputs, 2 Analog Outputs, 4 High Speed Counters, Up To 4 1769 I/O Expansion Modules, 4 CIP Motion Axis With Kinematics Function, 16 EtherNet/IP and 120 TCP Connections, 24V DC Embedded Power Supply, With 1GB SD Card, Can Support Up To 2GB SD Card, 1 USB Port. |
1769-L30ER | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 1MB Memory, 8 I/O Expansion, 16 Ethernet IP Nodes. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. |
1769-L30ERK | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 1MB Memory, 8 I/O Expansion, 16 Ethernet IP Nodes. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. - Conformally Coated |
1769-L30ERM | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 1MB Memory, 8 I/O Expansion, 16 Ethernet IP Nodes, 4 Axis CIP motion with Kinematics function. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. |
1769-L30ERMK | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 1MB Memory, 8 I/O Expansion, 16 Ethernet IP Nodes, 4 Axis CIP motion with Kinematics function. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. - Conformally Coated |
1769-L30ERMS | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 1MB standard + 0.5MB Safety Memory, 8 I/O Expansion, 16 Ethernet IP Nodes, 4 Axis CIP motion, Kinematics with Integrated Safety function. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. |
1769-L30ER-NSE | CompactLogix 5370 L3 Controller, Dual Ethernet w/DLR capability, 1MB Memory, 8 I/O Expansion, 16 Ethernet IP Nodes, No Supercap for RTC. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. |
1769-L33ER | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 2MB memory, 16 I/O Expansion, 32 Ethernet IP Nodes. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. |
1769-L33ERK | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 2MB memory, 16 I/O Expansion, 32 Ethernet IP Nodes. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. - Conformally Coated |
1769-L33ERM | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 2MB memory, 16 I/O Expansion, 32 Ethernet IP Nodes, 8 Axis CIP motion with Kinematics function. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. |
1769-L33ERMK | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 2MB memory, 16 I/O Expansion, 32 Ethernet IP Nodes, 8 Axis CIP motion with Kinematics function. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. - Conformally Coated |
1769-L33ERMO | Armor CompactLogix 5370 On Machine Controller, 2MB Memory, 16 I/O Expansion, 32 Ethernet/IP notes, 8 Axis CIP motion with Kinematics function, IP67, Controllers are shipped with 1GB SD card and support up to 2GB SD card. |
1769-L33ERMOS | Armor Compact GuardLogix 5370 On Machine safety Controller, 2MB/1MB Memory, 16 I/O Expansion, 32 Ethernet/IP notes, 8 Axis CIP motion with Kinematics function, IP67, Controllers are shipped with 1GB SD card and support up to 2GB SD card |
1769-L33ERMS | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 2MB standard + 1MB safety memory, 16 I/O Expansion, 32 Ethernet IP Nodes, 8 Axis CIP motion, Kinematics with Integrated Safety function. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. |
1769-L33ERMSK | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 2MB standard + 1MB safety memory, 16 I/O Expansion, 32 Ethernet IP Nodes, 8 Axis CIP motion, Kinematics with Integrated Safety function. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. - Conformally Coated |
1769-L36ERM | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 3MB memory, 30 I/O Expansion, 48 Ethernet IP Nodes, 16 Axis CIP motion with Kinematics function. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. |
| 1769-L36ERMO | Armor CompactLogix 5370 On Machine Controller, 3MB Memory, 30 I/O Expansion, 48 Ethernet/IP notes, 16 Axis CIP motion with Kinematics function, IP67, Controllers are shipped with 1GB SD card and support up to 2GB SD card. |
1769-L36ERMOS | Armor Compact GuardLogix 5370 On Machine safety Controller, 3MB/1.5MB Memory, 30 I/O Expansion, 48 Ethernet/IP notes, 16 Axis CIP motion with Kinematics function, IP67, Controllers are shipped with 1GB SD card and support up to 2GB SD card |
1769-L36ERMS | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 3MB standard + 1.5MB safety memory, 30 I/O Expansion, 48 Ethernet IP Nodes, 16 Axis CIP motion, Kinematics with Integrated Safety function. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. |
1769-L37ERM | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 4MB memory, 30 I/O Expansion, 64 Ethernet IP Nodes, 16 Axis CIP motion with Kinematics function. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. |
1769-L37ERMK | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 4MB memory, 30 I/O Expansion, 64 Ethernet IP Nodes, 16 Axis CIP motion with Kinematics function. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. - Conformally Coated |
1769-L37ERMO | Armor CompactLogix 5370 On Machine Controller, 4MB Memory, 30 I/O Expansion, 64 Ethernet/IP notes, 16 Axis CIP motion with Kinematics function, IP67, Controllers are shipped with 1GB SD card and support up to 2GB SD card. |
1769-L37ERMOS | Armor Compact GuardLogix 5370 On Machine safety Controller, 3MB/1.5MB Memory, 30 I/O Expansion, 64 Ethernet/IP notes, 16 Axis CIP motion with Kinematics function, IP67, Controllers are shipped with 1GB SD card and support up to 2GB SD card. |
1769-L37ERMS | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 4MB standard + 1.5MB safety memory, 30 I/O Expansion, 64 Ethernet IP Nodes, 16 Axis CIP motion, Kinematics with Integrated Safety function. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. |
1769-L37ERMSK | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 4MB standard + 1.5MB safety memory, 30 I/O Expansion, 64 Ethernet IP Nodes, 16 Axis CIP motion, Kinematics with Integrated Safety function. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. - Conformally Coated |
1769-L38ERM | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 5MB memory, 30 I/O Expansion, 80 Ethernet IP Nodes, 16 Axis CIP motion with Kinematics function. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. |
1769-L38ERMK | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 5MB memory, 30 I/O Expansion, 80 Ethernet IP Nodes, 16 Axis CIP motion with Kinematics function. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. - Conformally Coated |
1769-L38ERMO | Armor CompactLogix 5370 On Machine Controller, 5MB Memory, 30 I/O Expansion, 80 Ethernet/IP notes, 16 Axis CIP motion with Kinematics function, IP67, Controllers are shipped with 1GB SD card and support up to 2GB SD card. |
1769-L38ERMOS | Armor Compact GuardLogix 5370 On Machine safety Controller, 5MB/1.5MB Memory, 30 I/O Expansion, 80 Ethernet/IP notes, 16 Axis CIP motion with Kinematics function, IP67, Controllers are shipped with 1GB SD card and support up to 2GB SD card. |
1769-L38ERMS | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 5MB standard + 1.5MB safety memory, 30 I/O Expansion, 80 Ethernet IP Nodes, 16 Axis CIP motion, Kinematics with Integrated Safety function. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. |
1769-L38ERMSK | CompactLogix 5370 L3 Controllers, Dual Ethernet w/DLR capability, 5MB standard + 1.5MB safety memory, 30 I/O Expansion, 80 Ethernet IP Nodes, 16 Axis CIP motion, Kinematics with Integrated Safety function. Controllers are shipped with 1GB SD card and can support up to 2GB SD card. - Conformally Coated |
1769-ECLK | Left End Cap/Terminator- Conformally Coated |
1769-IA8IK | 8 Point 120 VAC Individually Isolated Input Module- Conformally Coated |
1769-IF4XOF2K | 8 Bit Resolution, High Speed 4 In/2 Out Anlg. Comb- Conformally Coated |
1769-OA16 | 16 Point 120/240 VAC Output Module |
1769-OA16K | 16 Point 120/240 VAC Output Module - Conformally Coated |
1769-OA8 | 8 Point 120/240 VAC Output Module |
1769-OB16 | 16 Point 24 VDC Sourcing Output Module |
1769-OB16K | 16 Point 24 VDC Sourcing Output Module - Conformally Coated |
